Stone Splitting Machine 1

• Place of Origin:

   Lebanon

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1442860

• Place of Origin:

  Lebanon
• This machine splits the tile into 2 parts. We put the tile in vertical way on the belt, and we specify the thickness of vertical split. We must regulate the thickness manually by moving the head of the disk left and right. It has 2 heads, one is used for splitting and the other is used for brake the tile finish. The tile must be polished very well to keep safe the rubber cylinder. The belt is controlled by an inverter.
  Heads count: 2
  Cutting height: 50-200 mm
  Cutting thickness: 5-80 mm
  Splitting thickness: 5-40 mm
  1 motor for the disk of splitting (RPM:1420 rotation): 11.25 kw
  1 motor for the disk of braking the tile finish (RPM:1420 rotation): 11.25 kw
  One variable Gearbox for the belt: 0.5 kw
  General power: 23 kw
  Overall dimensions (LxWxH): 3000x800x1300 mm
